Re: [cgal-discuss] Invalid TDS after inserting vertices and creating cells & neighbors
Chronological Thread
- From: Adam Getchell <>
- To:
- Subject: Re: [cgal-discuss] Invalid TDS after inserting vertices and creating cells & neighbors
- Date: Tue, 5 May 2015 21:30:56 -0700
Sorry, I should be explicit about my questions.
Hello all,I’m attempting to implement the (2,6) move which may be described pictorially as:However, it appears that once I insert a new vertex (v_center), the triangulation is re-calculated without taking into account the new cells and neighbors that I create in the following code (starting on line 207) of https://github.com/acgetchell/CDT-plusplus/blob/master/src/S3ErgodicMoves.h
The code in question is:
void move_26(Delaunay* const D3,
Cell_handle one_three_simplex,
unsigned neighbor_index,
Cell_handle three_one_simplex) noexcept {
// Preconditions
CGAL_triangulation_precondition((dimension() == 3)
&& (0 <= neighbor_index)
&& (neighbor_index < 4));
CGAL_triangulation_precondition(one_three_simplex.has_neighbor
(three_one_simplex));
CGAL_triangulation_expensive_precondition(is_cell(one_three_simplex,
three_one_simplex));
// Get vertices of common face
unsigned i1 = (neighbor_index + 1)&3;
unsigned i2 = (neighbor_index + 2)&3;
unsigned i3 = (neighbor_index + 3)&3;
Vertex_handle v1 = one_three_simplex->vertex(i1);
Vertex_handle v2 = one_three_simplex->vertex(i2);
Vertex_handle v3 = one_three_simplex->vertex(i3);
// Bottom vertex is the one opposite of the common face
Vertex_handle v_bottom = one_three_simplex->vertex(neighbor_index);
// Likewise, top vertex is one opposite of common face on the neighbor
Vertex_handle v_top = D3->mirror_vertex(one_three_simplex, neighbor_index);
// Debugging
std::cout << "Vertex index 1 is " << i1
<< " with coordinates of " << v1->point() << std::endl;
std::cout << "Vertex index 2 is " << i2
<< " with coordinates of " << v2->point() << std::endl;
std::cout << "Vertex index 3 is " << i3
<< " with coordinates of " << v3->point() << std::endl;
std::cout << "Vertex v_bottom is " << neighbor_index
<< " with coordinates of " << v_bottom->point() << std::endl;
std::cout << "Vertex v_top is " << neighbor_index
<< " with coordinates of " << v_top->point() << std::endl;
// Average vertices to get new one in their center
auto center_of_X = average_coordinates(v1->point().x(),
v2->point().x(),
v3->point().x());
auto center_of_Y = average_coordinates(v1->point().y(),
v2->point().y(),
v3->point().y());
auto center_of_Z = average_coordinates(v1->point().z(),
v2->point().z(),
v3->point().z());
// Debugging
std::cout << "Average x-coord is " << center_of_X << std::endl;
std::cout << "Average y-coord is " << center_of_Y << std::endl;
std::cout << "Average z-coord is " << center_of_Z << std::endl;
// Timeslices of v1, v2, and v3 should be same
CGAL_triangulation_precondition(v1->info() == v2->info());
CGAL_triangulation_precondition(v1->info() == v3->info());
// Insert new vertex
// Vertex_handle v_center = D3->insert(Point(center_of_X,
// center_of_Y,
// center_of_Z));
Point p = Point(center_of_X, center_of_Y, center_of_Z);
Vertex_handle v_center = D3->insert(p);
// Assign a timeslice to the new vertex
auto timeslice = v1->info();
std::cout << "Timeslice is " << timeslice << std::endl;
v_center->info() = timeslice;
std::cout << "Inserted vertex " << v_center->point()
<< " with timeslice " << v_center->info()
<< std::endl;
// Get neighbors
Cell_handle neighbor_13_1 = one_three_simplex->neighbor(i1);
Cell_handle neighbor_13_2 = one_three_simplex->neighbor(i2);
Cell_handle neighbor_13_3 = one_three_simplex->neighbor(i3);
Cell_handle neighbor_31_1 = three_one_simplex->neighbor(i1);
Cell_handle neighbor_31_2 = three_one_simplex->neighbor(i2);
Cell_handle neighbor_31_3 = three_one_simplex->neighbor(i3);
// Delete old cells
D3->tds().delete_cell(one_three_simplex);
D3->tds().delete_cell(three_one_simplex);
// Create new ones
Cell_handle bottom_12 = D3->tds().create_cell(v1, v_center, v2, v_bottom);
Cell_handle bottom_23 = D3->tds().create_cell(v2, v_center, v3, v_bottom);
Cell_handle bottom_31 = D3->tds().create_cell(v3, v_center, v1, v_bottom);
Cell_handle top_12 = D3->tds().create_cell(v1, v_center, v2, v_top);
Cell_handle top_23 = D3->tds().create_cell(v2, v_center, v3, v_top);
Cell_handle top_31 = D3->tds().create_cell(v3, v_center, v1, v_top);
// Set neighbors for bottom_12
bottom_12->set_neighbor(bottom_12->index(v_center), neighbor_13_3);
bottom_12->set_neighbor(bottom_12->index(v1), bottom_23);
bottom_12->set_neighbor(bottom_12->index(v2), bottom_31);
bottom_12->set_neighbor(bottom_12->index(v_bottom), top_12);
// Set neighbors for bottom_23
bottom_23->set_neighbor(bottom_23->index(v_center), neighbor_13_1);
bottom_23->set_neighbor(bottom_23->index(v2), bottom_31);
bottom_23->set_neighbor(bottom_23->index(v3), bottom_12);
bottom_23->set_neighbor(bottom_23->index(v_bottom), top_23);
// Set neighbors for bottom_31
bottom_31->set_neighbor(bottom_31->index(v_center), neighbor_13_2);
bottom_31->set_neighbor(bottom_31->index(v3), bottom_12);
bottom_31->set_neighbor(bottom_31->index(v1), bottom_23);
bottom_31->set_neighbor(bottom_31->index(v_bottom), top_31);
// Set neighbors for top_12
top_12->set_neighbor(top_12->index(v_center), neighbor_31_3);
top_12->set_neighbor(top_12->index(v1), top_23);
top_12->set_neighbor(top_12->index(v2), top_31);
top_12->set_neighbor(top_12->index(v_top), bottom_12);
// Set neighbors for top_23
top_23->set_neighbor(top_23->index(v_center), neighbor_31_1);
top_23->set_neighbor(top_23->index(v2), top_31);
top_23->set_neighbor(top_23->index(v3), top_12);
top_23->set_neighbor(top_23->index(v_top), bottom_23);
// Set neighbors for top_31
top_31->set_neighbor(top_31->index(v_center), neighbor_31_2);
top_31->set_neighbor(top_31->index(v3), top_12);
top_31->set_neighbor(top_31->index(v1), top_23);
top_31->set_neighbor(top_31->index(v_top), bottom_31);
} // move_26()
1. Is it correct to delete the two old cells before creating the new ones?2. Is there a way to create a vertex without inserting it into the Delaunay triangulation?3. If not, is there a way to prevent the Delaunay triangulation from re-triangulating with the newly inserted vertex before other operations are created?4. What is the correct way to create new cells in a region with older ones?5. How do I know that I need to change orientation (e.g. line 2097 in https://github.com/CGAL/cgal/blob/master/Triangulation_3/include/CGAL/Triangulation_data_structure_3.h )?Thanks for any advice!Adam Getchell
